NAKAMICHI NSM-6517

SPECIFICATIONS

  • Speaker Type: 6.5” (16.6cm)
  • Mounting Depth: >2.7” (67mm)
  • N-Power: 50W
  • Peak Power: 500W
  • Sensitivity (dB / W / m) : 90±3dB
  • Frequency Response : 113-15kHz
  • Impedance: 4Ω
  • Voice Coil: KSV 25.5mm
  • Magnet Mass: 15.4Oz (437g)
  • Net Weight: Approx. 2.1 kg


WHAT'S IN THE BOX

  1. NSM-6517 x 1pr
  2. Grille Net + Frame x 2pcs
  3. Screw (4×25mm) x 8pcs
  4. Gasket x 8pcs

DOWNLOADS

NSM-6517 Packaging user-manual
